Key Equipment List
PRECISION TURNING LONG SHAFTS CNC LATHES
TUR930MNx4M CNC Lathe
36.6″swing x 157.5″ between centers, 5.5″Bore, Fanuc 21iT Control. New 2013
L&L 950-6M
(5) Bed Way Heavy Duty CNC Lathe, 37.4” Cutting Dia. x 236.2” between centers w/programmable tailstock and hydraulic steady rests. 9″ dia spindle bore. Boring bar attachment. New 2012
Gurutzpe Model B1400
Heavy Duty 5-axis CNC Lathe, 63/48 x 567″ swing over carriage 48″, distance between centers 47′; live tooling
MTR Ravensburg
Hollow Center-drive Spindle CNC Lathe with (2) Tool Stations. Capable of machining bars 20″ dia. x 40′ (480”) Long (30,000 Lbs. Max.). Siemens 840D sl/828T Control Retrofit 2015
Poreba CNC TRP 93N
36″/21″ swing x 157″ between centers, 7.875″ dia. spindle bore
KEY SUPPORT EQUIPMENT
(Polishing, Deep Hole Drilling & Honing)
Lehmann Engine Lathe Polisher
34″ swing x 372″ between centers
Monarch Engine Lathe Polisher
22″ swing x 336″ between centers
Barnes Gun Drill
2-1/2″ dia. capacity x 10′ Stroke
Sliding Table HPM Straightening Press
500 Ton
Barnes Vertical Honing Machine
for bores up to 8″ dia. x 60″ long, Model 307
Barnes Vertical Honing Machine
for bores up to 6″ dia. x 36″ long, Model 307
MANUAL MILLS
Giddings & Lewis Model 350T
5″ Bar Horizontal Boring Mill with Digital Readout, 60″ x 98″ table, with tailstock and outboard supports
Giddings & Lewis
Model 300T Horizontal Boring Mill, 3″ Bar, with tailstock and outboard supports
Bridgeport
Milling Machine equipped with digital readout
Comet
Bridgeport Type Vertical Mill with digital readouts
CNC Mills
Parpas Quartz 4000
Moving column bed type 5 axis CNC mill w/ 6th axis indexer. Longitudinal travel 157″, cross travel 47″, vertical travel 62″. Heidenhein iTNC530 control. New 2008
Mazak
AJV60/80 Bridge Type CNC 3 Axis Vertical Machining Center X=79″, Y=55″, Z=20″. 35HP, 30 ATC
Mazak
AJV35/80 Bridge Type CNC 4 Axis Vertical Machining Center X=79″, Y=35″, Z=20″. 35HP, 30 ATC; spline milling capability
LONG BAR MANUAL TURNING LATHES
Poreba TR115-13M Engine Lathe
45″ swing x 512″ between centers, twin carriages
Poreba TRI15-13 Engine Lathe
45″ swing x 315″ between centers
Poreba TPK90N Engine Lathe (qty 2)
36″/48″ swing x 236″ between centers
SUPPORT, TOOL ROOM & FIXTURING SMALL MANUAL LATHES
Wafum Model TUR560 Engine Manual Lathe
21″ swing, 120″ between centers
Wafum Model TUR630 Engine Manual Lathe
21″ swing, 80″ between centers
LeBlond Manual Lathe
17″ swing, 52″ between centers
GRINDERS (Centerless, I.D. & Blanchard)
Cincinnati Milacron
#3EA Centerless Grinder, 5″-11″ capacity, 22′ long
Heald Internal Grinder
Model #72A for I.D. Grinding up to 15″ dia. x 60″ long. (Short work pieces as large as 30″ O.D.)
42″ Blanchard Grinder
Swings 48″ across corners of workpiece
